Classification	Radio channel relay unit
Device type	Wireless
Installation method	Into electric switchboard, junction box
Compatibility	Operates with all Ajax hubs, and range extenders
Actuating element	Electromagnetic relay
Relay service life	200,000 switch-ons
Voltage protection	Max — 36.5 V, min — 6.5 V
Maximum load current	5A at 36V DC, 13A at 230V AC
Maximum current protection	No
Maximum temperature protection	> 65°C at the place of installation
Electric power meter function	No
Energy consumption parameter check	Voltage
Power supply	7 - 24 V (DC only)
Operation modes	Impulse Bistable
Contact state	Normally open Normally closed
Adjustable pulse duration	0.5–255 sec
Jeweller radio technology	Communication range with central unit — up to 1,000 m in an open space Two-way communication between devices Operating frequencies — 868.0 - 868.6 MHz Self-adjusting RF output power — up to 25 mW Block encryption based on AES algorithm Device scanning period — 12 - 300 s
Operating temperature range	From 0°С to +64°С
Permissible humidity	Up to 75%
Protection class of body	IP20
Anti-sabotage	Protection against fraud Jamming detection
Remote setting and testing	+
Dimensions	39 × 33 × 18 mm
Weight	25 g
Warranty	Replacement and repair within 24 months of the date of sale.
Service life	10 years
Complete set	Relay Installation set User's guide
